Reference Information
Packaging Type: Bag, Reel, Tray
Low-Halogen Status: Low-Halogen per IEC 61249-2-21, Not Low-Halogen per IEC 61249-2-21, Not Relevant, Not Reviewed per IEC 61249-2-21
Glow-Wire Capable: Yes
Use With Series: 172708, 172709, 172718, 172762, 172765, 172767, 200453, 200471, 200488, 202988, 203070, 203603, 204723, 207017, 219670, 219671, 30490, 42474, 42475, 43760, 44516, 45750, 46012, 5556, 5557, 5558, 5559
Electrical
Voltage - Maximum: 600V
Current - Maximum per Contact: 6A to 13.5A
Mechanical
Pitch - Mating Interface: 4.2mm
Circuits (maximum): 2 to 24
Wire Size (AWG): 16 to 28
Durability (mating cycles max): 10 to 100
Physical
Material - Resin: High Temperature Thermoplastic, Liquid Crystal Polymer (LCP), Nylon
Material - Metal: Brass, Copper Alloy, High Performance Alloy (HPA), Phosphor Bronze
Plating min - Mating: 0.762µm to 2.54µm
Temperature Range - Operating: -40° to +105°C, -40° to +125°C, -40° to +80°C
